Dynamic Scale Loop (Differential Scale Loop)
Production engineers are responsible for the design, operation and
efficiency of water handling systems in which thermal, pressure or
chemical changes lead to scale deposition.
Dynamic Scale Loop with 10,000 psi max pressure
DSL System with Cooling & Heating Capability
6,000 psi System
Oven with Fan and Window, Filter/Core Holder
In-line pH Probe
Our dynamic scale loops provide an accurate, reproducible and fast methods
for selecting and quantifying the most effective means of controlling
scale deposition under dynamic pipeline conditions.
The instrument is suitable to simulate process or reservoir temperatures
of up to 280 °C and pressures of up to 1,000 bar
(14,500 psi). Higher ratings can be provided if required. An
integrated pH probe ist available. The system is very
recommended where effects of pressure on scaling tendency are to be
studied, and especially for examining the deposition of anhydride under
dynamic conditions.
This instrument offers a variety of advantages:
Automated test and cleansing routines programmable
Determination of minimal inhibitor concentration: manual or with two automated procedures
Extended number of brines/inhibitors with optional mixing bank
Optional pH / conductivity probe with automated data logging
Optional pipeline cooling
Several PEEK/Monel/Hastelloy options for high corrosive applications
The test pipelines are easily exchangeable with standard connections.
The test pipelines have a defined inner roughness, which is highly
important to assure reproducible test results.
Besides manual operation, our scale loops offer 2 different automated
test methods:
Tube Blocking Test (TBT): The scale inhibitor concentration
is decreased along a defined curve until scale is detected.
NEW! Scale Equilibrium Test (SET):
The scale inhibitor concentration is increased until a scale
equilibrium is achieved.
Applications:
Scale inhibitor development and testing
Scale inhibitor efficiency tests
NEW! Corrosion tests on test sheets and
test rods
Absolute pressure ratings from 100 bar (2,900 psi) to
1,000 bar (14,500 psi) available
Differential pressure: 5, 10 or 20 bar (72, 145 or
290 psi)
Resolution: 0.5, 1 or 2 mbar (0.007, 0.015 or
0.029 psi)
3-pump system (more accurate than 2-pump systems)
PEEK pumps heads available up to 200 bar
(5,800 psi)
Flow rate: max 5, 10 or 20 ml/min per pump
Flow rate transducers (summarised flow or per pump flow)+
optionally available
Pipeline temperature: 280 °C max (pipeline cooling
optional)
Touch-screen color display
PC with software for data visualisation and storage
(Windows 7/8/10/11)
weight: approx. 60 to 140 kg (depending on model)
dimension (WxHxD): approx.
120 x 65 x 60 cm (depending on model)
mains power: 240 VAC / 50/60 Hz or 120 VAC /
60 Hz or 208 VAC / 60 Hz
If you are interested in further information, please send us a short message using our
We will immediately send you the data sheet Dynamic Scale Loop (Differential Scale Loop).
